Information about the film stretching system

The clamps at the transfer point must be reliably positioned at the edge of the material to ensure trouble-free production at a high process speed. The specific sensors and actuators from Erhardt+Leimer make this operation dependable. With the ELTIM basis weight measurement, the mass distribution from the extruder to the rewinder is reliably monitored during all steps of the stretching process. Of course, the material thickness as derived from the basis weight can also be displayed and, in this way, a target thickness adopted.

Systems and products for the film stretching system

Basis weight measuring system ELTIM BWS10

Traversing, contact-free basis weight and thickness measurement for the foil and battery industry

More info

Flange load cell, steel PD 21/22

High flexibility thanks to different shaft diameters ranging from 12 to 65 mm and nominal measuring forces ranging from 0.05 to 10 kN

More info

Flange load cell, aluminum PD 25/26

Cost-effective flange load cell made of aluminum with an anodized surface

More info
