Information about the digital printing machine

These days, a modern printing machine includes precise web guiding and printing belt control. The web guiding should transfer the web to the printing belt quickly and precisely. The most important requirement during the professional printing of knitted fabrics is an optimal web tension. Particularly with highly elastic knitted fabrics, several web tension controls may be used in the infeed. Furthermore, a web width control can help with the correctly positioned transfer of the web to the printing belt with the required width without creases, but with completely spread edges. Optionally, web cleaning can be very useful. Seams between the items always represent waste. Seam detectors ensure that the print head is raised at seams and there is no printing in these areas.

Systems and products for digital printing machines

Web guiding and spreading system ELSMART SWS94

Precise web guiding for woven and knitted fabrics in dry and damp operation at a machine speed of up to 200 m/min with electric actuating drive

More info

Web guiding and spreading system ELSMART SWS95

Precise web guiding for woven and knitted fabrics in dry and damp operation at a machine speed of up to 220 m/min with electric actuating drive

More info

Conveyor belt control system ELBANDER VGA36

Conveyor belt control system for use on conveyor belt lines with high tensile forces

More info

Conveyor belt control system ELBANDER VGA20

Compact conveyor belt control system with mechanical edge detection for a load of 5,000 N

More info

Conveyor belt control system ELBANDER VGA19

Compact conveyor belt control system with mechanical edge detection for a load of 2,500 N

More info

Flange load cell, steel PD 21/22

High flexibility thanks to different shaft diameters ranging from 12 to 65 mm and nominal measuring forces ranging from 0.05 to 10 kN

More info

Flange load cell, aluminum PD 25/26

Cost-effective flange load cell made of aluminum with an anodized surface

More info
