Information about the stenter

The stenter is a drier with a revolving chain. The chain can be designed with either pin carriers or clips, or a combined chain can be equipped with pin carriers and clips. The chain can be adjusted according to the web width. In this way, the exit can also be adjusted to the required web width. Before pinning at the stenter machine infeed, there is the so-called overfeed, using this device significantly more web can be pinned per meter chain (up to 50 %). This "overlength" allows the textile to "shrink" (relax) in the drier, which gives the textile high dimensional stability even after various washing and drying cycles. Thanks to the stenter infeed and various selvedge opening devices, even difficult curled edges can be spread and the web applied to the pin chain with minimal over-pinning. There is also very often a very wide variety of coating devices in the infeed.

Systems and products for stenters

Stenter infeed KRS60

Precise web selvedge pinning through dynamic control and CCD infrared sensor

More info

Web guiding and spreading system ELSMART SWA95

Precise web guiding for woven and knitted fabrics in dry and damp operation at a machine speed of up to 130 m/min with pneumatic actuating drive

More info

Web guider KF 2020

Web guider with mechanical edge detection and pneumatic operation

More info

Web guider KF 2040

Web guider with mechanical edge detection and electric operation

More info

Web guider KF 2060

Web guider with optoelectronic edge detection and electric operation

More info

Flange load cell, steel PD 21/22

High flexibility thanks to different shaft diameters ranging from 12 to 65 mm and nominal measuring forces ranging from 0.05 to 10 kN

More info

Flange load cell, aluminum PD 25/26

Cost-effective flange load cell made of aluminum with an anodized surface

More info

Web cutting system ELCUT BTA80

Edge cutting system for edge trimming on knitted fabrics

More info

Web cutting system ELCUT BTB01

Shear cut principle with driven bottom and top blades for edge cuts on paper, foil, textile, carpet, non-woven fabric, and felt webs

More info
