Information about the fabric inspection machine

Fabric inspection machines are these days still an essential element in machine facilities, irrespective of whether defect inspection is undertaken by eye or using cameras. As a rule, a roll is produced at the exit. Web guiding is required in the infeed to wind the roll cleanly. For highly elastic knitted fabrics, we supply machines with a certified length measurement. Web tension control also aids more uniform length consistency.

Systems and products for fabric inspection machines

Web guiding and spreading system ELSMART SWA95

Precise web guiding for woven and knitted fabrics in dry and damp operation at a machine speed of up to 130 m/min with pneumatic actuating drive

More info

Flange load cell, steel PD 21/22

High flexibility thanks to different shaft diameters ranging from 12 to 65 mm and nominal measuring forces ranging from 0.05 to 10 kN

More info

Flange load cell, aluminum PD 25/26

Cost-effective flange load cell made of aluminum with an anodized surface

More info
