Information about the extrusion line

On extrusion lines, rubber webs of varying profile (side wall, apex, tread) or flat webs such as the airtight inner layer of the tire are produced by means of direct extrusion or using roller head systems. E+L offers tried-and-trusted solutions to keep the webs produced in position, to cut them, to laminate them with other materials and to measure the profile or thickness. In this way, an optimal result and the highest quality are ensured.

Systems and products for extrusion lines

Steering roller system ELROLLER SRB43

Compact steering roller system for nominal widths of 400 to 2,400 mm and a maximum web tension of 700 N

More info

Complexer laminating station

Laminating station for precise laminating of rubber strips

More info

CCD camera OL 91

Used to detect various criteria for position control on moving webs with complete image processing within the camera

More info

Triangulation sensor SL 23

Intelligent triangulation sensor with dual matrix camera and integrated laser light

More info

CCD camera OL 82

Interruption-free detection of web edges, position detection, web guiding, material detection, and width measurement

More info

Infrared edge sensor PoE FR 54

Infrared edge sensor based on the principle of retroreflection with a measuring range of ±10 mm and a resolution of 0.02 mm

More info

Sensor roller for one-sided mounting PD 40

Aluminum roller with two integrated load cells and a roller diameter from 60 to 120 mm

More info

Infrared wide band sensor FE 46

Digital infrared wide band sensor for web center detection, web edge detection, and width measurement with a tube distance (clear width) of 160 mm

More info

Analog measuring amplifier CV 22

Single-channel measuring amplifier for connecting two fabric tension sensors to a strain gauge bridge

More info

Digital web tension controller DC 62

Compact, digital web tension controller for different control structures including color touch-display

More info

Measuring amplifier with display PA 62

Digital two-channel measuring amplifier for connection of 2 fabric tension sensors with a strain gauge bridge

More info

Motorized support beam VSB97

Motorized support beam for cutting blade positioning

More info
