Information about the transfer printing machine

During transfer printing, the textile web is fed, precisely positioned, to the printed thermo-transfer paper. The web guiding should be positioned as close as possible in front of the transfer cylinder. However, because the thermo-transfer cylinder is very hot, necessary clearances must be taken into account.

Systems and products for transfer printing machines

Web guiding and spreading system ELSMART SWS95

Precise web guiding for woven and knitted fabrics in dry and damp operation at a machine speed of up to 220 m/min with electric actuating drive

More info

Web guider KF 2020

Web guider with mechanical edge detection and pneumatic operation

More info

Web guider KF 2040

Web guider with mechanical edge detection and electric operation

More info

Web guider KF 2060

Web guider with optoelectronic edge detection and electric operation

More info

Flange load cell, steel PD 21/22

High flexibility thanks to different shaft diameters ranging from 12 to 65 mm and nominal measuring forces ranging from 0.05 to 10 kN

More info

Flange load cell, aluminum PD 25/26

Cost-effective flange load cell made of aluminum with an anodized surface

More info
